Overview
The AAM11B is a versatile Current/Voltage Input Module by YOKOGAWA, supporting BRAIN communication. It provides accurate input signal handling and flexible power supply options.
Features
- Model: AAM11B
- Input Signal: 0 to 20 mA DC
- Transmitter Power Supply: 25.0 to 25.5 V DC
- Auxiliary Voltage Output: 1 to 5 V DC
- Square Root Extraction: Available by specifying
Technical Specifications
- Input Resistance: 250 Ω
- Allowable Input Voltage/Current: 40 mA DC or less
-
Accuracy Rating:
- Voltage Input: ±4 mV
- Current Input: ±16 µA
- Auxiliary Voltage Output: ±12 mV
-
Effect of Ambient Temperature:
- Voltage Input: ±4 mV and ±0.15% per 10°C
- Current Input: ±32 µA
- Auxiliary Voltage Output: ±24 mV
- Data Update Period: 50 ms
- Current Consumption: 300 mA or less (5.0 V DC)
- Signal Insulation: Insulated between systems
- Withstanding Voltage: 1500 V AC/min
Installation & Wiring
- Installation: Install in I/O Module Nest
- Wiring: Connect to terminal of I/O Module Nest with M4 screws
Additional Information
- Input Signal Settings: Configured via software
