General Information
- Product ID: GJR5253000R0200
- ABB Type Designation: 07KT97
- Catalog Description: 07KT97 PLC Central unit, 24V DC
Additional Information
-
Ambient Air Temperature:
- Operation: 0 ... +55 °C
- Storage: -25 ... +75 °C
-
Analog Inputs:
- 8 channels, 0 ... +5V, -5 ... +5V (10 bit + sign)
- 0 ... +10V, -10 ... +10V (11 bit + sign)
- 0 ... 20mA, 4 ... 20mA
- PT100 (2 or 3 wire, 12 bit, bipolar)
- Usable as digital inputs
-
Analog Outputs:
- 4 channels, -10 ... +10V (11 bit + sign)
- 0 ... 20mA (12 bit)
-
CS31-Bus: 1
-
Invoice Description: 07KT97 PLC Central unit, 24V DC
-
Maximum Hardware Counter Input Frequency: 50 kHz
-
Maximum Number of Analog I/Os: 232 AI, 228 AO
-
Maximum Number of Digital I/Os: 1024
-
Medium Description: 07KT97
-
Memory Size User Data: 256 kB
-
Memory Size User Program: 480 kB
-
Memory Type User Data: Flash EPROM
-
Memory Type User Program: Flash EPROM, non-volatile RAM, SMC
-
Minimum Order Quantity: 1 piece
-
Number of Analog Configurable I/Os: 0
-
Number of Digital Configurable I/Os: 8
-
Number of Digital Inputs DC 24V: 24
-
Number of Digital Outputs DC 24V: 16
-
Number of Hardware Counters: 2
-
Order Multiple: 1 piece
-
Output Current: 0.5 A
-
Output Voltage (Uout): 24 V DC
-
Part Type: New
-
Primary Voltage: 24 V
-
Product Depth: 85 mm
-
Product Main Type: 07KT97
-
Product Name: 07KT97 PLC Central unit, 24V DC
-
Product Net Weight: 5.71 kg
-
Product Type: Spare_Parts
-
Programming Software: AC1131
-
Serial Port 1 Type: RS232 / Programming, Modbus Master or slave
-
Serial Port 2 Type: RS232 / Modbus Master or slave, ASCII
-
Short Description: 07KT97: AC31, Prog. Logic Controller 480KB
-
Speed for 1000 instructions (65% Logic, 35% Word): 0.3 ms
