Overview
The ABB 07 KR 264 is a programmable controller (PLC) designed for industrial automation applications. It offers a combination of inputs, outputs, and programming capabilities, making it suitable for various control tasks.
General
- Integrated User Program Memory: 1 K EEPROM (950 words)
- External Program Storage: 2 K EEPROM or 2 K EPROM (1970 words)
- Cycle Time: Typically 5 ms/K instructions
- Supply Voltage: 230 V AC (+15%, -25%), 50/60 Hz
- Power Consumption: 39 VA without programming unit
- Connections: Screw terminals
- Timers: 40
- Time Range: 0.01-999 s
- Down Counters: 16, 3 decades each
- Up/Down Counters: 8, 4 decades each
- High-Speed Upward Counter: 1, with 4 decades, 10 kHz
- LED Display: For inputs/outputs and operating modes
- Flags: 376 (including 248 buffered flags)
- Diagnosis: Cycle monitoring, programming error, and checksum
- Programming: Miniature programming unit, IBM PC or compatible PC via 07 PG 201
- Permissible Temperature Range: 0 °C to 55 °C in operation, -10 °C to 65 °C storage
- Humidity Class: 90 without condensation
- Dimensions: 330 L x 140 H x 102 W
Inputs
- Number of Inputs: 40
- Supply Voltage: 24 V DC (integrated)
- Input Data: Isolated via optocouplers
- Input Delay: 4 ms
- Input Current: 10 mA
Outputs
- Number of Outputs: 24 (expandable to max. 64)
- Output Data: Relay outputs (230 V AC, cosφ= 1: Imax. 2 A, 230 V AC, cosφ=0.4: Imax. 1 A, 230 V DC/24 V DC: Imax. 1 A, 230 V AC/24 V AC, 230 V DC/24 V DC: Imin. >25 mA)
- Contact Protection: Varistor when switching inductive loads
- Output Delay: Typically 10 ms
- Contact Service Life: Unloaded: 20 x 10⁶ switching cycles, Loaded 230 V AC/2A: 2 x 10⁵ switching cycles
