General Information
- Product ID: GJR5253100R0278
- ABB Type Designation: 07KT98
- Catalog Description: 07KT98S90, SPS (AC1131), ETHER.+
Additional Information
-
Ambient Air Temperature:
- Operation: 0 ... +55 °C
- Storage: -25 ... +75 °C
-
Analog Inputs:
- 8 channels: 0 ... +5V, -5 ... +5V (10 bit + sign), 0 ... +10V, -10 ... +10V (11 bit + sign), 0 ... 20mA, 4 ... 20mA, PT100 (2 or 3 wire, 12 bit, bipolar); inputs can also be used as digital inputs
-
Analog Outputs:
- 4 channels: -10 ... +10V (11 bit + sign), 0 ... 20mA (12 bit)
- CS31-Bus: 1
- Fieldbus Interface Type: Ethernet TCP/IP, CANopen master
Technical Specifications
- Frame Size: Spare Parts
- Invoice Description: 07KT98S90, SPS (AC1131), ETHER.+
- Made To Order: No
- Maximum Hardware Counter Input Frequency: 50 kHz
- Maximum Number of Analog I/Os: 232 AI, 224 AO
- Maximum Number of Digital I/Os: 1040
- Memory Size User Data: 1000 kB
- Memory Size User Program: 1000 kB
- Memory Type User Data: Flash EPROM
- Memory Type User Program: Flash EPROM, non-volatile RAM, SMC
- Number of Digital Configurable I/Os: 8
- Number of Digital Inputs DC 24V: 24
- Number of Digital Outputs DC 24V: 16
- Number of Hardware Counters: 2
- Object Classification Code: K
- Output Current: 0.5 A
- Output Voltage (Uout): 24 V DC
- Part Type: New
- Primary Voltage: 24 V
- Product Depth: 85 mm
- Product Main Type: 07KT98
- Product Name: 07KT98S90, SPS (AC1131), ETHER.+
- Product Net Weight: 1 kg
- Product Type: Spare Parts
- Programming Software: AC1131
- Serial Port 1 Type: RS232 / Programming, Modbus Master or Slave
- Serial Port 2 Type: RS232 / Modbus Master or Slave, ASCII
- Short Description: 07KT98-ETH-CAN, Prog. Log. Controller
- Speed for 1000 Instructions (65% Logic, 35% Word): 0.07 ms
- Terminal Type: Screw Terminals, Pluggable
