General Info
- Article Number: 3BSC690087R1
- Type: Analog Output
- Signal Specification: 4...20 mA
- Number of Channels: 8
- Signal Type: Unipolar single ended
- HART: Yes
- SOE: No
- Redundancy: No
- High Integrity: No
- Intrinsic Safety: Yes
Detailed Data
- Resolution: 12 bit
- Isolation: Groupwise isolated from ground
- Under/Over Range: 2.5 / 22.4 mA
-
Output Load:
- <725 ohms at 20 mA, no over-range
- <625 ohms at up to 22 mA
- Error: Typ. 0.05%, Max. 0.1% at 650 ohms
- Temperature Drift: Typ. 50 ppm/°C, Max. 100 ppm/°C
- Rise Time: 30 ms (10% to 90%)
- Current Limiting: Short circuit proof current limited output
- Rated Insulation Voltage: 50 V
- Dielectric Test Voltage: 500 V a.c.
- Power Dissipation: 4.25 W
- Current Consumption +5 V Modulebus: Typ. 130 mA
- Current Consumption +24 V External: Typ. 250 mA, Max. <330 mA
Dimensions
- Width: 45 mm (1.77”)
- Depth: 102 mm (4.01”), 111 mm (4.37”) including connector
- Height: 119 mm (4.7”)
- Weight: 0.2 kg (0.44 lbs.)
