Overview
The S800 I/O system is a versatile, distributed, and modular process I/O solution that connects with controllers and PLCs via industry-standard field buses. At the core of this system is the CI801 Fieldbus Communication Interface (FCI) module, which offers a range of configurable communication functions. The CI801 handles tasks such as signal processing, supervision data collection, output signal processing (OSP), Hot Configuration InRun, HART pass-through, and the configuration of I/O modules. The FCI module connects to the controller using the PROFIBUS-DPV1 fieldbus protocol.General Info
- Article number: 3BSE022366R1
- Communication protocol: PROFIBUS DP-V1
- Master or slave: Slave
- Line redundancy: No
- Module redundancy: No
- Hot Swap: No
- Used together with HI Controller: Yes
Detailed Data
- 24 V consumption (typical): 140 mA
Environment and Certification
- CE-marking: Yes
-
Electrical Safety:
- EN 61010-1
- UL 61010-1
- EN 61010-2-201
- UL 61010-2-201
-
Hazardous location:
- C1 Div 2 cULus
- C1 Zone 2 cULus
- ATEX Zone 2
-
Marine certificates:
- ABS
- BV
- DNV-GL
- LR
-
Operating temperature: 0 to +55 °C (+32 to +131 °F)
- Approvals are issued for +5 to +55 °C
- Storage temperature: -40 to +70 °C (-40 to +158 °F)
- Pollution degree: Degree 2, IEC 60664-1
- Corrosion protection: ISA-S71.04: G3
- Relative humidity: 5 to 95%, non-condensing
-
Max ambient temperature:
- 55 °C (131 °F)
- For vertical mounting: 40 °C (104 °F)
- Protection class: IP20 according to EN60529, IEC 529
- RoHS compliance: DIRECTIVE/2011/65/EU (EN 50581:2012)
- WEEE compliance: DIRECTIVE/2012/19/EU
Dimensions
- Width: 85.8 mm (3.38 in.)
- Height: 136 mm (5.35 in.) including latch
- Depth: 58.5 mm (2.30 in.)
- Weight: 0.3 kg (0.66 lbs.)
