General Information
- Extended Product Type: CP630
- Product ID: 1SAP530100R0001
- ABB Type Designation: CP630
- EAN: 4016779864886
- Catalog Description: CP630 Control Panel 5.7" TFT touch screen
-
Long Description:
- 5.7" TFT touch screen, 64K colors, 320 x 240 pixels
- PB610 runtime license
Additional Information
-
Ambient Air Temperature:
- Operating: 0 ... +50 °C
- Storage: -20 ... +70 °C
- CN8: 85371091
-
Communication Interface:
- 2x Ethernet 100 MBit
- 1x RS232/422/485
- 2x USB 2.0 Host
- 1x SD card slot
- 2x Expansion slots
- Country of Origin: Italy (IT), Germany (DE), Finland (FI)
- Customs Tariff Number: 85371091
-
Declaration of Conformity:
- C-Tick: For CP620(-WEB), CP630(-WEB), CP635(-WEB), CP650(-WEB), CP660(-WEB), CP675(-WEB)
- KCC: Conforms with EMC standards for industrial devices regulated by the Korea Communications Commission (KCC)
-
Degree of Protection:
- Front: IP66 (IEC 60529)
- Housing: IP20 (IEC 60529)
Product Specifications
- Frame Size: Undefined
- Gross Weight: 1.3 kg
-
Housing Material:
- Front Side: Zamak
- Reverse Side: Aluminium
- Invoice Description: CP630 Control Panel 5.7" TFT touch screen
- Made to Order: No
- Maximum Order Quantity: 0 pieces
-
Memory Size:
- User Data: 128 MB
- User Program: 256 MB
-
Memory Type:
- User Data: Flash Disk
- User Program: DDR RAM
- Mounting Type: Front face
- Power Consumption: 16.8 W
- Power Supply: 24 V DC (18 ... 30 V DC)
- Product Type: PLC-CP600
- Programming Software: PB610 Panel Builder 600
- Real-time Clock: Hardware clock, battery backup
-
Screen:
- Type: TFT color, LED backlight, touch screen
- Color: 64K colors
- Resolution: 320 x 240 pixels
- Size: 5.7 inches (4:3 screen)
- Security: Password protection with 8 user levels
Dimensions & Packaging
-
Product Net Dimensions:
- Depth/Length: 51 mm
- Height: 147 mm
- Width: 187 mm
- Weight: 0.82 kg
-
Package Level 1 Dimensions:
- Depth/Length: 280 mm
- Height: 120 mm
- Width: 210 mm
- Units: 1 carton
Additional Details
- Service Life: 40,000 hours
-
USB Ports:
- Type 1: Host, version 2.0
- Type 2: Host, version 2.0
- Serial Port 1 Type: RS232/RS422/RS485
- Selling Unit of Measure: Piece
-
Stocked At:
- Menden, Germany
- Singapore, Singapore
- Hangzhou, China
- Bairro Santo Antonio, Brazil
- UNSPSC: 32151703
-
WEEE:
- B2B (Business to Business)
- Category 5: Small Equipment (No External Dimension More Than 50 cm)
- eClass: 27-33-02-01
