General Information
- Extended Product Type: DC522
- Product ID: 1SAP240600R0001
- ABB Type Designation: DC522
- EAN: 4016779655972
- Catalog Description: Digital input/output module, 16 configurable DI/DO, 24VDC 0.5A, 8 auxiliary terminals (0 V) and 8 auxiliary terminals (24VDC)
- Long Description: DC522: S500 Digital input/output module with 16 configurable DI/DO at 24VDC 0.5A, 8 auxiliary terminals for 0 V, and 8 auxiliary terminals for 24VDC, supports 2-3 wire connections.
Ordering Information
- CN8: 85389091
- Invoice Description: Digital input/output module with 16 configurable DI/DO at 24VDC 0.5A, 8 auxiliary terminals for 0 V, and 8 auxiliary terminals for 24VDC (DC522)
- Made To Order: No
- Minimum Order Quantity: 1 piece
- Order Multiple: 1 piece
- Selling Unit of Measure: Piece
Dimensions
- Product Net Weight: 0.102 kg
- Product Net Depth / Length: 62 mm
- Product Net Height: 76 mm
- Product Net Width: 67.5 mm
- Gross Weight: 0.126 kg
-
Package Level 1 Dimensions:
- Depth / Length: 84 mm
- Height: 72 mm
- Width: 71 mm
- Units: 1 carton
Technical Specifications
- Function: 16 configurable DI/DO, 24VDC 0.5A, 8 auxiliary terminals for 0 V, and 8 auxiliary terminals for 24VDC
- Number of Analog Configurable I/Os: 0
- Number of Digital Configurable I/Os: 16
- Input Voltage Type: DC
- Input Current: 5 mA
- Maximum Input Voltage: 0 ... 30 V
- Delay Time (τ): 0.1 … 32 ms
- Output Type: Transistor
- Output Voltage Type: DC
- Output Voltage (Uout): 24 V DC
- Output Current: 0.5 A
- Output Voltage Maximum: 20.4 … 28.8 V
- Degree of Protection: IP20
- Supply Voltage: 20.4 … 28.8 V DC
-
Ambient Air Temperature:
- Operation: 0 ... +60 °C
- Storage: -40 ... +70 °C
Additional Information
- Product Main Type: DC522
- Product Name: Distributed Automation I/Os
Classifications
- eClass: 27-24-22-04
- ETIM 8: EC001419 - PLC digital I/O-module
- UNSPSC: 32151705
Environmental Information
- SCIP: 3057eee4-0247-4304-9e95-58b4d0688cb8 (Germany)
- WEEE B2C / B2B: Business To Business
- WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)
