General Info
- Article number: 3BSE008508R1
- Type: Digital Input
- Signal specification: 24 V d.c.
- Number of channels: 16
- Signal type: Current sinking
- HART: No
- SOE: No
- Redundancy: No
- High integrity: No
- Intrinsic safety: No
- Mechanics: S800
Detailed Data
- Input voltage range, "0": -30..+5 V
- Input voltage range, "1": 15..30 V
- Input impedance: 3.5 kΩ
- Isolation: Groupwise isolated from ground, 2 groups with 8 channels
- Filter times (digital, selectable): 2, 4, 8, 16 ms
- Current limiting: Sensor power can be current limited by the MTU
- Maximum field cable length: 600 meters (656 yards)
- Rated insulation voltage: 50 V
- Dielectric test voltage: 500 V a.c.
- Power dissipation: Typ. 1.8 W
- Current consumption +5 V Modulebus: 50 mA
- Current consumption +24 V Modulebus: 0
- Current consumption +24 V external: 0
Dimensions
- Width: 45 mm (1.77”)
- Depth: 102 mm (4.01”), 111 mm (4.37”) including connector
- Height: 119 mm (4.7”)
- Weight: 0.15 kg (0.33 lbs)
