General Info
- Article number: 3BSE013212R1
- Type: Digital Input
- Signal specification: 48 V d.c.
- Number of channels: 16
- Signal type: Current sinking
- HART: No
- SOE: Yes
- Redundancy: No
- High integrity: No
- Intrinsic safety: No
- Mechanics: S800
Detailed Data
- Input voltage range, "0": -60 .. +10 V
- Input voltage range, "1": 30 .. 60 V
- Input impedance: 9.6 kΩ
- Isolation: Groupwise isolated from ground
- Filter times (digital, selectable): 0...100 ms
- Current limiting: Sensor power can be current limited by the MTU
- Maximum field cable length: 600 meters (656 yards)
- Event recording accuracy: -0.3 ms...+0.7 ms
- Event recording resolution: 0.4 ms
- Rated insulation voltage: 50 V
- Dielectric test voltage: 500 V a.c.
- Power dissipation: Typ. 3.2 W
- Current consumption +5 V Modulebus: Typ. 100 mA, Max. 120 mA
- Current consumption +24 V Modulebus: 0
Compatibility
- Use with MTU: TU810, TU812, TU814, TU818, TU830, TU833, TU838, TU850
- Keying code: BD
Dimensions
- Width: 45 mm (1.77”)
- Depth: 102 mm (4.01”), 111 mm (4.37”) including connector
- Height: 119 mm (4.7”)
- Weight: 0.22 kg (0.48 lbs.)
