Overview
The RLM02 module converts a non-redundant PROFIBUS line into two redundant RS485 lines or vice versa. It can be positioned directly after a master, before a bus segment with multiple slaves, or before an individual slave. PROFIBUS stations equipped with redundant couplers can connect directly to a PROFIBUS line set to redundant mode by the RLM02.
Specifications
- Compatibility: PROFIBUS DP/FMS lines
- Automatic Line Selection: Enables automatic switch between lines
- Transmission Rate: 9.6 kbit/s to 12 Mbit/s
- Communication Monitoring: Built-in
- Repeater Functionality: Integrated for signal boosting
- Wiring: 8-pin terminal strip, supports up to 1.5 mm² wire cross section
- Redundant Power Supply: 24 VDC (range: +20 to +33 V), typical consumption of 120 mA at 24 V
- Operating Temperature: 0°C to 50°C
- Status and Error Display: Visual indicators for system status and errors
- Power Supply Monitoring: Monitors power levels for stable operation
- Potential-Free Signaling Contact: For additional flexibility
- Installation: Easy assembly on a DIN mounting rail
