General Information
- Article Number: 3BSE020848R11
- Communication Protocol: Modulebus
- Master or Slave: N/A
- Line Redundancy: Yes
- Hot Swap: No
- Type: Redundant TB840/TB840A, Single I/O, Single Power
- Power Input: 24 V d.c (19.2 - 30 V)
- Mounting: Vertical or Horizontal
Detailed Data
-
ModuleBus Current Distribution:
- Maximum 5 V: 1.5 A
- 24 V: 1.5 A
- Mechanical Keys: 36 different combinations
-
Acceptable Wire Sizes:
- Solid: 0.2 - 2.5 mm²
- Stranded: 0.2 - 2.5 mm², 24 - 12 AWG
- Recommended Torque: 0.5 Nm
- Rated Insulation Voltage: 50 V
- Dielectric Test Voltage: 500 V a.c
- Power Dissipation: 2.0 W
Environment and Certification
- CE Marking: Yes
-
Electrical Safety Certifications:
- EN 61010-1
- UL 61010-1
- EN 61010-2-201
- UL 61010-2-201
-
Hazardous Location Certification:
- cULus Hazardous Location Class 1 Zone 2
- ATEX Zone 2
-
Marine Certificates:
- ABS
- BV
- DNV-GL
- LR
- Operating Temperature: 0 to +55 °C (+32 to +131 °F)
(Approvals are issued for +5 to +55 °C) - Storage Temperature: -40 to +70 °C (-40 to +158 °F)
- Relative Humidity: 5 to 95 %, non-condensing
-
Max Ambient Temperature:
- 55 °C (131 °F) for horizontal mounting
- 40 °C (104 °F) for vertical mounting
- Equipment Class: Class I according to IEC 60536 (Earth protected)
- Ingress Protection: IP20 according to IEC 60529
- RoHS Compliance: DIRECTIVE/2011/65/EU (EN 50581:2012)
- WEEE Compliance: DIRECTIVE/2012/19/EU
Dimensions
- Width: 124 mm (4.88 in.)
- Height: 186 mm (7.32 in.) including latch
- Depth: 47 mm (1.85 in.)
- Weight: 0.45 kg (0.99 lbs.)
