Overview
The Pre-Wired Cable for standard 1756 16-point I/O Modules offers an efficient solution for machine building and system integration. This cable is designed to increase productivity and simplify the engineering process by reducing wiring time and minimizing wiring errors.
Key Benefits:
- Increases machine building productivity
- Simplifies design and engineering time
- Reduces wiring time and minimizes errors
- Enhances the appearance of control panels
- Supports conversions from Modicon 800 and 1771 PLC-5® systems to 1756 ControlLogix® I/O
- Various models and cable lengths available in the 1492 Programmable Controller wiring systems series on abb.com.
- Contact NHP for further information.
Specifications
-
Product Series: 1492 Programmable Controller Wiring Systems
-
Component Type: Pre-Wired Cable
-
Termination: Wiring with 1756-TBNH Connector and IFM 20-Pin Connector
-
Compatible Modules:
- 1756IA16
- 1756IN16
- 1756IB16
- 1756IC16
- 1756IV16
- 1756OA16
- 1756OB16E
- 1756OV16E
-
Number of Conductors: 20
-
Wire/Conductor Size: 22 AWG (0.326 mm²)
-
Cable Jacket Diameter: 9 mm
-
Cable Length: 1 meter (3.28 feet)
-
Insulation Voltage:
- Rated Insulation Voltage (AC): 300 V
- Rated Insulation Voltage (DC): 300 V
-
Temperature Ratings:
- Insulation Temperature: 80°C
-
Storage Temperature:
- Min: -20°C
- Max: 80°C
-
Environmental Conditions:
-
Relative Humidity:
- Min: 5% RH
- Max: 95% RH
-
Relative Humidity:
-
Pollution Degree: 2
-
Certifications:
- CE
- C-UL-US
- UL
- FM
