Overview
The 1606-XLS DIN-rail power supply is known for its exceptional features, including high efficiency and compact size, made possible through synchronous rectification and innovative design. This unit offers a short-term peak power capability of 150% and large output capacitors, allowing it to start motors, charge capacitors, and absorb reverse energy. These features often enable the use of a smaller unit than expected.
Additional highlights include:
- High immunity to transients and power surges
- Low electromagnetic emissions, making it suitable for almost any environment
- Integrated output power manager and a wide input voltage range
- Minimal inrush current on the input for easy installation
- Diagnostic features: dry DC-ok contact, green DC-ok LED, red overload LED
- Quick-connect spring-clamp terminals for fast, safe installation
- Large international approval package for various applications
Specifications
- Output Voltage: 24V DC
- Adjustment Range: 24-28V
-
Output Current:
- 10A continuous at 24V
- 15A for typ. 4s at 24V
-
Output Power:
- 240W continuous at 24V
- 360W for typ. 4s at 24V
- Output Ripple: < 50mVpp (20Hz to 20MHz)
-
Input Voltage:
- AC 100-240V ±15%
- DC 110-300V, -20%/+25%
- Line Frequency: 50-60Hz ±6%
-
AC Input Current:
- 2.22A at 120Vac
- 1.22A at 230Vac
-
Power Factor:
- 0.98 at 120Vac
- 0.92 at 230Vac
-
AC Inrush Current:
- 4A peak at 120Vac
- 7A peak at 230Vac
-
DC Input Current:
- 2.37A at 110VDC
- 0.87A at 300VDC
-
Efficiency:
- 92.3% at 120Vac
- 93.0% at 230Vac
-
Losses:
- 20.0W at 120Vac
- 18.1W at 230Vac
-
Temperature Range:
- Operational: -25°C to +70°C
- Derating: 6W/°C from +60°C to +70°C
-
Hold-up Time:
- Typ. 27ms at 120Vac
- Typ. 28ms at 230Vac
Dimensions:
- Width: 60mm
- Height: 124mm
- Depth: 117mm
