Specifications
-
Outputs:
- 8 N.O. (Normally Open)
- 8 N.C. (Normally Closed)
- Individually isolated (two points per group)
-
Pilot Duty: C300/R150
-
Operating Voltage Range:
- 5…125V DC
- 10…240V AC
-
Contact Current Rating:
- 1 A @ 5…30V DC
- 0.5 A @ 48V DC
- 0.22 A @ 125V DC
- 1.5 A @ 120V AC (50/60 Hz)
- 0.75 A @ 240V AC (50/60 Hz)
-
Output Delay Time:
- Off to On: 13 ms max
- On to Off: 13 ms max
-
Current Draw:
- @ 5.1V: 100 mA
- @ 24V: 100 mA
-
Total Backplane Power: 2.9 W
-
Power Dissipation: Max 3.1 W @ 60 °C (140 °F)
-
Thermal Dissipation: 10.57 BTU/hr
-
Off-State Leakage Current per Point: Max 0 mA
-
Minimum Load Current per Point: 10 mA
-
Initial Contact Resistance: Max 100 mΩ @ 6V 1 A
-
Switching Frequency: Max 1 operation/3 s (0.3 Hz at rated load)
-
Bounce Time: Mean: 1.2 ms
-
Expected Contact Life:
- 300 kHz resistive
- 100 kHz inductive
-
Scheduled Outputs: Synchronization within 16.7 s max, reference to the Coordinated System Time
-
States in Fault Mode per Point: Hold last state, On or Off (Off is default)
-
States in Program Mode per Point: Hold last state, On or Off (Off is default)
-
Isolation Voltage: 250V (continuous), basic insulation type, outputs-to-backplane, and output-to-output
-
Routine Tested: 1350V AC for 2 s
