Overview
The MicroLogix 1200 is a compact and versatile programmable logic controller (PLC) designed for small-scale automation tasks. It comes with integrated I/O and several advanced features to meet the needs of a variety of industrial applications.
Key Features:
-
I/O Configuration:
- 14 Digital Inputs (24V DC, Sink/Source type)
- 10 Relay Outputs (NO 125V DC / 250V AC type)
- 4 Latching or Pulse-Catch Inputs
- 4 Interrupt Inputs
- 1 High-Speed Counter Input (Shared)
- 10 Digital Outputs (24V DC type)
-
Communication Ports:
- RS-232 / RS-485 Serial Ports (for network communication)
-
Communication Protocols Supported:
- DF1 Half-Duplex
- Modbus RTU
- ASCII
- Radio Modem (optional)
-
Power Supply:
- Input Voltage: 120/240V AC
-
Memory:
- Program Memory: 4 kB
- Data Memory: 2 kB
-
Expansion Capabilities:
- Expands up to 136 I/O points
- Supports up to 6 local expansion modules (Bulletin 1762 MicroLogix™ Expansion I/O modules)
-
High-Speed Features:
- 20kHz High-Speed Counter
- Built-in Limit Switch Function
- Two built-in ¾-turn trim potentiometers
-
Additional Features:
- Real-time clock (optional)
- No built-in display
- Base Unit Plug-In Slots: None
Environmental Specifications:
- Operating Temperature: 0°C to 55°C
- Storage Temperature: -40°C to 85°C
- Relative Humidity (Max): 95% RH
- Shock Acceleration (Max.): 30 g
- Vibration Acceleration (Max.): 5 m/s²
- Vibration Displacement (Peak-to-Peak Max.): 0.762 mm
- Vibration Frequency (Max.): 500 Hz
