Overview
The FLEX I/O™ terminal base is an essential component for connecting I/O modules in industrial automation systems. It attaches to the DIN rail next to the I/O adapter and provides terminal connection points for I/O wiring, creating a backplane when modules are connected together. Available with cage, screw, or spring-clamp terminations, the terminal base is designed to work seamlessly with various FLEX I/O modules. Optional accessories are available depending on the I/O module and system setup.
Key Features
- Compact Design: Wire directly from the sensor to the terminal base, eliminating the need for a terminal strip, saving space.
- High Functionality: Supports 4- to 32-point modules with functionality comparable to larger rack-based I/O systems.
- Enhanced Productivity: Simplified configuration and setup with built-in wizards to speed up engineering and installation processes.
- Reduced Downtime: Features Removal and Insertion Under Power (RIUP) and built-in diagnostics to minimize system downtime.
- Extensive Options: Over 90 catalogue numbers, including specialty modules, to meet a wide range of application requirements.
- Harsh Environment Support: Conformal coated and extreme environment-rated modules are available for challenging operational conditions (contact NHP for more details).
- Network Flexibility: Compatible with EtherNet/IP™, ControlNet™, DeviceNet™, and PROFIBUS DP for flexible network integration.
- Improved Operations: HART analog modules allow seamless data transfer to asset management software or controllers for improved plant operations.
Specifications
-
Terminal Screw Torque:
1.4 Nm (12 lb-in) -
Supply Voltage Range:
V/COM Terminals: 250V DC/AC, 50/60 Hz, 10 A -
Isolation Voltage:
Capable of 250V (continuous) maximum, Basic Insulation Type.
Field Wiring Terminals to FLEXBUS, or the lesser of the installed module's specifications. -
Wire Size:
Solid or stranded copper wire, rated at 75°C (167°F) or greater.
Wire size range: 0.34 – 3.3 mm² (22 – 12 AWG).
Maximum insulation: 1.2 mm (3/64 in.).
Strip length: 5 – 6 mm (0.20 – 0.24 in.). -
Dimensions (HxWxD) with Module Installed in Terminal Base:
94 x 94 x 69 mm (3.7 x 3.7 x 2.7 in.)
