Overview
The PanelView Plus 6 Terminal, 600 Model is a compact and powerful operator interface designed to deliver enhanced performance and connectivity.
- Display: 5.7-inch color display with both Keypad/Touch functionality.
- Communications: Ethernet, RS-232, and Modular Communications Interface.
- Power: AC Input.
Key Improvements over the PanelView Plus 600:
- Processor speed increased from 350 MHz to 1 GHz.
- Screen transition rate up to 70% faster.
- System memory upgraded from 64MB RAM to 256MB RAM.
- Flash storage space expanded from 64MB to 512MB.
- Enhanced LED backlight for better display illumination.
- Greater connectivity to peripherals such as printers, mice, and keyboards.
Additional Features:
- Supports ActiveX® Controls.
- Integrates with third-party software like Microsoft Internet Explorer® and Microsoft Office Viewer.
- Remote connectivity via VNC and FTP.
- Backup and restore functionality.
- Remote recipe and data management through CSV files.
- Uses vector-based graphics from Symbol Factory.
- Built-in PDF viewer for context-sensitive operator support.
- Supports DataStore Plus for logging and trending, eliminating the 300,000 data point limit.
Specifications
- Component Type: Operator Panel
- Operator Input Method(s): Keypad/Touch
- Display Size: 5.7 inches
- Display Resolution: 320 x 240 pixels
- Display Brightness: 440 cd/m²
- Display Backlight: LED
- Display Backlight Life: 25,000 hours
- Touch Screen Type: Resistive
Dimensions:
- Height, Cutout: 142 mm
- Width, Cutout: 241 mm
- Height: 167 mm
- Width: 266 mm
- Depth: 98 mm
- Weight: 0.728 kg
Environmental Ratings:
- IP Rating (Front): IP66
- Marine Certified: No
-
Operating Temperature:
- Max: 55°C
- Min: 0°C
-
Storage Temperature:
- Max: 70°C
- Min: -25°C
-
Relative Humidity:
- Min: 5% RH
- Max: 95% RH
Performance & Standards:
- Software, Configuration: FactoryTalk View Studio Machine Edition
- Shock Acceleration (Max.): 15 g
- Shock Duration (Max.): 11 ms
- Shock Rating: IEC 60068-2-27
- Vibration Acceleration (Max.): 2 m/s²
- Vibration Displacement (Peak to Peak Max.): 0.012 mm
- Vibration Frequency (Operational Max.): 500 Hz
- Vibration Rating: IEC 60068-2-6
