Overview
The 3500/94M VGA Module displays all 3500 Machinery Protection System information, including:
- System Event List
- Alarm Event List
- All Module and Channel Data
- Alarm and OK Status
- Nine Custom Display Options
The module allows configuration of up to nine custom screens using the 3500 Rack Configuration Software. By default, one screen displays all 1X-filtered vibration measurements, while another screen shows the proximity transducer gap values.
Specifications
Inputs
- Power Consumption: 4.6 watts max.
- High-Speed Network: Monitors status, data, and values.
- RS232 Port (I/O): Touch controller data.
Outputs
- OK LED: Indicates proper operation of the module.
- TX/RX LED: Indicates communication between system modules.
- VGA Port (I/O): Provides analog red, green, blue, and sync signals to the display.
- Front Port: 24 Vdc power out, VGA signal out, touch commands in.
Environmental Limits
- Operating Temperature: -20°C to 65°C (-22°F to 149°F)
- Storage Temperature: -40°C to 85°C (-40°F to 185°F)
- Humidity: 95%, non-condensing.
