Overview
The 3300 XL 8 mm Proximity Transducer System includes the following components:
- One 3300 XL 8 mm probe
- One 3300 XL extension cable
- One 3300 XL Proximitor Sensor
The system provides an output voltage directly proportional to the distance between the probe tip and the observed conductive surface. It can measure both:
- Static (position) values
- Dynamic (vibration) values
Primary applications:
- Vibration and position measurements on fluid-film bearing machines
- Keyphasor reference and speed measurements
Specifications
Proximitor Sensor
- Input: Accepts one non-contacting 3300-series 5 mm or 3300 XL 8 mm Proximity Probe and Extension Cable.
-
Power Requirements:
- Requires -17.5 Vdc to -26 Vdc when installed with non-incendive circuit (as per installation drawing 140979) with a maximum consumption of 12 mA.
- Requires -23 Vdc to -26 Vdc when using barriers.
- Operation at a more positive voltage than -23.5 Vdc may result in reduced linear range.
-
Supply Sensitivity:
- Less than 2 mV change in output voltage per volt change in input voltage.
- Output Resistance: 50 Ω
System
- Length: 5 or 9 meters (including extension cable), or 1 meter (probe only).
- Materials: A308 aluminum.
- Weight: 246 g (8.67 oz).
| Quick Quotes | Receive price & availability FAST from our dedicated customer service team. |
|---|---|
| Delivery | Expedited, Freight, And International Shipping Available. |
| Condition | 100% New with Original Package |
| Payment | We accept American Express, Discover, MasterCard, PayPal, and Visa. Our site is secured by RapidSSL. |
| Shipping Port | ShangHai, Xiamen |
| Warranty | 12 Months |
| Q: Is Our Pricing Competitive? |
| A: Yes, we collaborate with over 50 countries worldwide. As a top supplier in China, we offer significant discounts based on market trends. |
| Q: What Is the Warranty Period? |
| A: All our new and original products come with a standard one-year warranty. |
| Q: What Payment Methods Do We Accept? |
| A: We require 100% T/T (Telegraphic Transfer) payment before shipping. For items with a lead time, a 30% deposit is needed upfront, and the remaining 70% is due before shipping. If you have a representative in China, you can arrange an RMB transfer through them. |
| Q: What Shipping Methods Do We Use? |
| A: We primarily use FedEx, DHL, UPS, and BRE for shipping. If you have an account with any of these carriers, you can handle shipping directly. We also offer free shipping to China-based freight forwarders. |
| Q: What Is Our Delivery Time? |
| A: Delivery usually takes 1-3 days after receiving the initial payment. For items with a lead time, shipping will occur according to the specified schedule. |
| Q: How Do We Package the Goods? |
| A: We ensure safe packaging with multiple layers of protection. Products are first placed in their original boxes and sealed with labels. A layer of bubble wrap is then added for collision protection during transit. Finally, the items are packed securely in durable boxes. |
| Q: How Can Customers Contact Us and Request a Quote? |
| A: You can reach out to us via email, WhatsApp, WeChat, Skype, or your preferred communication platform. Contact us with your needs, and we'll provide a prompt, customized quote. |
