Overview
The 3300 XL 25 mm Transducer System includes a separate 25 mm probe, an extension cable, and a 3300 XL 25 mm Proximitor Sensor. It features an output of 0.787 V/mm (20 mV/mil), providing a linear measurement range of 12.7 mm (500 mils). This system is specifically designed for measuring differential expansion (DE) in mid-size to large steam turbine generators, addressing the differing growth rates between the turbine rotor and the machine stator (casing).Specifications
-
Operating Temperature:
-51°C to +100°C (-60°F to +212°F) -
Storage Temperature:
-51°C to +105°C (-60°F to +221°F) -
Relative Humidity:
100% condensing, non-submersible when connectors are protected. Tested to IEC 68-2-3 damp heat. -
Weight (Typical):
Proximitor Sensor: 255 g (9 oz)
Ordering Information
3300 XL 25 mm Proximity Probe
Model Number: 330850-AA-BB
A: Total Length and Mounting Option
- 50: 5.0 metres (16.4 feet) system length, panel mount
- 51: 5.0 metres (16.4 feet) system length, DIN mount
- 90: 9.0 metres (29.5 feet) system length, panel mount
- 91: 9.0 metres (29.5 feet) system length, DIN mount
B: Agency Approval Option
- 00: No Approvals
- 05: Multiple Approvals
