Overview
The 4-Channel Relay Module is a full-height module that provides four relay outputs. It can be installed in any slot to the right of the Rack Interface Module, with multiple 4-Channel Relay Modules being used as needed. Each relay output on the module can be independently programmed to execute specific voting logic.
The module features "Alarm Drive Logic" for each relay. This logic can be configured using AND and OR operations and can incorporate alarming inputs (alerts and dangers) from any or multiple monitor channels within the rack. The programming of this Alarm Drive Logic is managed through the 3500 Rack Configuration Software, allowing for customization to fit the particular requirements of the application.
Specifications
-
Operating Temperature: -30 °C to +65 °C (-22 °F to +150 °F)
-
Storage Temperature: -40 °C to +85 °C (-40 °F to +185 °F)
-
Humidity: 95%, non-condensing
-
Dimensions:
-
Height: 241 mm (9.50 in)
-
Width: 24.4 mm (0.96 in)
-
Depth: 242 mm (9.52 in)
-
-
Weight: 0.7 kg (1.6 lb)
-
Rack Space Requirements: 1 full-height front slot
