Overview
- Purpose: Designed to measure absolute (relative to free space) vibration of bearing housing, casing, or structural components.
- System Components: Two-wire systems consist of a transducer and appropriate cable.
Specifications
-
Operating and Storage Temperature:
- 9200: -29°C to +121°C (-20°F to +250°F)
- 74712: -29°C to +204°C (-20°F to +400°F)
-
Environment: Dust and moisture resistant.
-
Relative Humidity:
- Up to 95% non-condensing.
- 100% non-submerged when ordered with integral cable.
-
Case and Adapter Material: Anodized aluminum A204.
-
Gasket Material:
- 9200: Neoprene
- 74712: Silicone
-
Connector Material: Options: Cadmium-plated aluminum, neoprene, and silver-plated copper.
-
Terminal Block Option: Polyphenylene Sulfide with nickel-plated copper contacts.
-
Mounting Torque:
- Mounting base options: 1/2-20, 1/4-20, 1/4-28, 5/8-18, or M10X1.
-
Torque specifications:
- 5.6 N•m (50 in•lb) for mounting base options.
- 1.41 N•m (12.5 in•lb) for 8-32 threaded studs.
-
Dimensions:
- Height: 102 mm (4 in) typical (depending on connector option).
- Diameter: 41 mm (1.6 in) typical.
-
Weight:
- 9200: 300 grams (10.5 ounces) typical.
- 74712: 480 grams (17 ounces) typical.
-
Transducer Orientation: All Seismoprobe Velocity Transducers are specified for mounting orientation.
