Overview
The PR9268/301-000 is an electrodynamic velocity sensor from EPRO, optimized for horizontal orientation. This sensor delivers accurate vibration measurements in various industrial applications, ensuring reliable performance even in challenging conditions.
Features
- Horizontal Orientation: Operates effectively within ±10° without lifting or sinking current.
- High Sensitivity: Offers sensitivity of 28.5 mV/mm/s (723.9 mV/in/s).
- Wide Frequency Range: Measures vibrations from 4 to 1000 Hz.
-
Low Transverse Sensitivity:
- 0.13 for PR9268/20x-x00 at 110 Hz
- 0.27 for PR9268/30x-x00 at 110 Hz
- Mechanical Limits: Handles vibration amplitudes up to 3000 µm (4000 µm peak-to-peak).
Technical Specifications
- Natural Frequency: 4.5 Hz ± 0.75 Hz at 20°C (68°F)
- Amplitude Linearity: Less than 2%
-
Maximum Acceleration:
- Continuous: 10 g (98.1 m/s²) peak-to-peak
- Intermittent: 20 g (196.2 m/s²) peak-to-peak
- Maximum Transverse Acceleration: 2 g (19.62 m/s²)
- Damping Factor: ~0.56 at 20°C (68°F), ~0.42 at 100°C (212°F)
- Resistance: 1875 Ω ± 10%
- Inductance: ≤ 90 mH
- Active Capacity: Less than 1.2 nF
Environmental & General
- Power Source: Self-powered
- Operating Temperature Range: -20 to +100°C (-4 to 212°F)
- Protection Class: IP55
- Relative Humidity: 0 to 100%, non-condensing
Material
- Composition: Al Mg Si Pb F 28
Dimensions & Weight
- Weight: 930 g
