ZW0502/1217/0211 Overview
The EPRO ZW0502/1217/0211 is a robust converter designed for compatibility with Epro's eddy current sensors. It ensures precise signal conversion for reliable monitoring of machinery vibration and displacement in various industrial applications.
ZW0502/1217/0211 Technical Specifications
- Input Type: Eddy current sensors
- Operating Temperature Range: -30°C to +100°C (-22°F to 212°F)
- Frequency Range (-3 dB): 0 to 20,000 Hz
- Rise Time: < 15 µs
-
Supply Voltage Range:
- -23V to -32V (Output Range -4V to -20V)
- -21V to -32V (Output Range -2V to -18V)
- Shock and Vibration: 5g @ 60 Hz @ 25°C (77°F)
- Protection Class: IP20
- Housing Material: PA 6.6
- Weight: ~60 grams (2.12 oz)
- Mounting: DIN Rail
- Connections: Screw Terminal (Max. 1.5 mm², Wire-end Sleeves)
PR6423/005-0F2 Overview
The EPRO PR6423/005-0F2 is a high-precision Eddy Current Sensor designed for non-contact measurement of vibration and displacement. It is particularly suitable for monitoring critical machinery such as turbines, compressors, and pumps.
PR6423/005-0F2 Technical Specifications
- Linear Measurement Range: 0 to 5 mm
-
Incremental Scale Factor (ISF):
- 8 V/mm (203.2 mV/mil) ± 5% @ temperature range 0 to 45°C (32 to 113°F)
-
Deviation from Best Fit Straight Line (DSL):
- ± 0.025 mm (± 1 mil) @ temperature range 0 to 45°C (32 to 113°F)
- Initial Air Gap: 0.5 mm (20 mils)
- Minimum Shaft Diameter: 25 mm (0.79 in)
- Target Material: Ferromagnetic Steel (42CrMo4, AISI/SAE 4140)
- Protection Class: IP66, IEC 60529
-
Operating Temperature Range:
- Sensor (including 1m Cable): -35 to +200°C (-31 to 392°F)
- Cable & Connector: -35 to +150°C (-31 to 302°F)
-
Material:
- Sensor Tip: PEEK (Polyether Ether Ketone)
- Case: Stainless Steel
- Cable: PTFE (Polytetrafluoroethylene)
- Connector: Brass, nickel-plated
- Weight (Sensor with 1m Cable): Approx. 100 grams (3.53 oz)
