Overview
The GE Fanuc D25-0158-000001 is a versatile digital input/output module designed for reliable and flexible digital I/O functions in industrial automation. Its customizable options and advanced features make it suitable for various control and monitoring tasks.
Digital Inputs
- General: Up to 96 optically isolated (5000 Vrms), organized in cards of 32 inputs
-
Digital Input Options:
- 12, 24, 48, 120, 250 Vdc ±20%, bipolar inputs
- Burden: 1.2 to 10 mA, maximum power dissipation 0.5 W per input
- Contact Debounce: Three-level programmable software filtering for debounce and chatter
-
Configurable Input Types:
- Digital input
- Sequence of Events with 1 ms time-tagging accuracy
- Change of State
- Pulse Accumulator (up to 8 digital inputs)
- On-Board Wetting: Yes
Digital Outputs
-
Standard Digital Outputs:
- 16 or 32 relay outputs
- Single component failure protection and detection
- Select-check before execute security
-
Configurable Output Types:
- Latching (On/Off)
- Trip/Close
- Raise/Lower
- Programmable pulse duration from 5 to (231-1) ms in 1 ms intervals
- Output Relay Contacts: 1 Form A
-
Maximum Switching Power:
- 60 W or 125 VA (resistive)
-
Maximum Switching Voltage:
- 75 Vdc or 50 Vac (DB-25)
- 120 Vdc (FACE-40)
- Maximum Switching Current: 2 A
- Maximum Carrying Current: 2 A
- Operate Time: 5 ms
- Release Time: 5 ms
- Breakdown Voltage: 1500 Vac for one minute (coil to contact)
-
Isolation between Adjacent Outputs:
- 300 Vdc (with compression terminal block)
- 100 Vdc (with DB-25 connectors)
- Interposing Relay Option: Groups of 8 digital outputs can interface directly to D20KI module
