Features:
- Non-volatile flash memory for program storage.
- Programming support in Ladder Diagram and Instruction List.
-
Battery backup for program, data, and time-of-day clock:
- Super capacitor provides power to memory for 1 hour.
- Beyond 1 hour, the backup battery protects memory contents for up to 6 months.
- Backup battery has a shelf life of 5 years when not in use.
- Run/Stop switch.
- Floating point (real) data functions.
- Embedded RS-232 and RS-485 communications.
- Supports EZ Program Store device (IC200ACC003).
- 70mm height when mounted on a DIN rail with the power supply.
Specifications
- Size: 2.63” (66.8mm) x 5.04” (128mm)
-
I/O Discrete Points:
- 2048 In
- 2048 Out
- Discrete Internal Bits: 1024 points
- Discrete Temporary Bits: 256 points
- Global Discrete Bits: 1280 points
-
Configurable Memory (Program, Registers, I/O Analog Words):
- CPU001: 42KB maximum
- CPU002: 42KB maximum
- Boolean Execution Speed: 1.8ms/K (typical)
- Floating Point: Yes
- Override: Yes
- Built-in Ports: RS-232, RS-485
- Built-in Communications: SNP Slave, RTU Slave, Serial I/O
- Type of Memory Storage: System flash, battery-backed RAM
- Battery-Backed Real-time Clock: Yes
- Realtime Clock Accuracy (for timers or timer contacts): 100ppm (0.01%) or +/- 9sec/day
-
Time-of-Day Clock Accuracy:
- 23ppm (0.0023%) or +/- 2sec/day at 30°C
- 100ppm (0.01%) or +/- 9sec/day at full temperature range
