Overview
The IC200MDL740 is a discrete output module that provides one group of 16 discrete outputs. These outputs are positive or sourcing type outputs, switching loads to the positive side of the DC supply to supply current to the loads.
Specifications
Module Characteristics
- Points: 1 group of 16 outputs
- Module ID: FFFF8080
-
Isolation:
- User input to logic (optical) and to frame ground
- Group to group
- Point to point
-
Voltage Ratings:
- 250VAC continuous
- 1500VAC for 1 minute
- Not applicable to point-to-point isolation
-
LED Indicators:
- One LED per point shows the individual point’s on/off state
- FLD PWR LED: Indicates field power is present
- OK LED: Indicates backplane power is present
-
Backplane Current Consumption:
- 5V output: 45mA maximum
-
External Power Supply:
- Input range: +10.2 to +30VDC, +12/24VDC nominal
- Thermal Derating: See diagram
Output Characteristics
- Output Voltage: +10.2 to +30VDC, +12/24VDC nominal
- Output Voltage Drop: 0.3V maximum
-
Load Current:
- 0.5A at 30VDC maximum (resistive)
- 2.0A inrush maximum for 100ms
- Output Leakage Current: 0.5mA at 30VDC maximum
- On Response Time: 0.2ms maximum
- Off Response Time: 1.0ms maximum
- Protection (Each Output): No internal fuse
