Overview
The DS200TCQCG1BHF is an Analog I/O Expander Board designed by General Electric for the Mark V Series. It is primarily used in gas and steam turbine control systems, specifically for medium- to large-duty turbines. This board features a triple-redundant system for critical control backup, making it a key component in the EX2000 subset of the Mark V Series.
Hardware Features
-
Connectors:
- 11 vertical pin cable connectors
- 5 male vertical pin header connectors
- 1 female vertical plug
-
Components:
- 6 relay components
- Over 25 resistor network arrays
- 40+ integrated circuits
- Ceramic capacitors, diodes, and metal film resistors
- Jumpers: 37 jumper switches (important to replicate jumper settings from the previous board)
- Heat Sink: Included for heat dissipation
- Mounting: Drilled in each corner for mounting, with edge markings for proper alignment
Functional Description
- Primary Function: Provides excitation to the LVDT (Linear Variable Differential Transformer) and LVDR (Linear Variable Differential Resistor).
- Redundancy: Part of a triple-redundant system using R/S/T processors for multiple backups in critical control systems.
Installation Notes
- Alignment: Ensure proper positioning and alignment of connectors and jumpers during installation.
