Overview
The module is equipped with four miniature fuses, each dedicated to protecting the corresponding circuit. Every fuse is paired with an LED that indicates its status. Fuse conditions are continuously monitored by an evaluation logic, which updates the status of each circuit through the respective LED.
The front-facing contact pins (1, 2, 3, 4, and L-) are used to connect L+ (or EL+) and L- for supplying power to the I/O modules and sensor contacts.
Specifications
-
Fuses: Max. 4 A slow blow
-
Switching time: Approx. 100 ms (relay)
-
Loadability of relay contacts: 30 V/4 A (continuous load)
-
Residual voltage in case of fuse tripped: 0 V
-
Residual current in case of fuse tripped: 0 mA
-
Residual voltage in case of missing supply: Max. 3 V
-
Residual current in case of missing supply: < 1 mA
-
Space requirement: 4 TE
-
Operating data (24 V DC): 60 mA
