Overview
The Honeywell 900B08-0202 is an 8-channel analog output module designed for industrial automation applications. It provides precise and reliable control of analog outputs, making it suitable for various process control and machine automation tasks.
Technical Specifications
- Manufacturer: Honeywell
- Product Number: 900B08-0202
- Product Type: Analog Outputs 0 to 20mA, 8 Channel
- Outputs per Module: 8, isolated in 2 groups of 4 outputs
- Current: 0 to 21.0 mA, range selectable
- Load Resistance: 750 ohms max
- Galvanic Isolation: 500VDC group to group and from logic
- Accuracy: 0.1% full scale at reference conditions
- Modules per Rack: 4 max (powered from internal 24V backplane power)
- Minimum Current Sensing: >0.5mA per output
- Calibration Data: Non-volatile memory, redundant factory calibration, individual channel field calibration
- Diagnostics: Monitoring of Factory Calibration, Field Calibration, Configuration
- Output Verification: Feedback to controller to indicate output current is flowing
- D/A Resolution: 13+ bits (1 part in 13,332)
-
Power Supply Loading:
- 5V; 225 mA max
- 24V; 350 mA max
- Terminal Block: 36 Position – Euro style (Model 900TCK0001)
- Dimensions: 137 mm H x 35.6 mm W (5.4" x 1.4")
- Weight: 0.4 kg
