Performance and Capability
- Maximum I/O Modules per controller: 144
- Maximum Analog Channels per controller: 230
- Maximum Digital Channels per controller: 460
- Maximum Expansion I/O Racks for Non-Redundant Controller: 11
- Maximum Expansion I/O Racks for Redundant Controller: 12
- Command Execution Time: 85 µs per 1000 commands in ST
Item Specification
- Processor: Dual Core ARM® Cortex™-A9 Core (32-bit) 667 MHz
-
User Programming Memory (Flash):
- User: 10 MB (Program 5 MB, Data 5 MB)
- Total: 256 MB (Flash)
- SD Card Support: 32GB Class 6 / Class 10 industry standard
- Running Memory (RAM): 256 MB with Error Correction Code
- Controller Redundancy: Supported (Hot Standby)
- Real-Time Clock: 2 weeks of retention after a power loss
- CPU Watchdog: CPU automatically resets if error is detected
- Nonvolatile Memory Data Life: 20+ years (no battery required)
- Real-Time Clock Resolution: 1 ms
- I/O Scan Time: 10 ms – 3000 ms (adjustable per control strategy)
-
Switchover:
- Internal parameters, variables, and outputs are maintained during transition
- Switchover Time: <100 ms
-
Operating Modes:
- Run Locked
- Stop Locked
- Remote Running
- Remote Stopped
- LEDs: 2 LEDs, three colors each, indicate the status and role of the CPM
- Max. Current @5V: 750 mA
- Max. Current @24V: 0 mA
- Heat Dissipation (W): 3.75 W
