Overview
The CC-PAON01 is a high-level analog output module designed to provide precise 4-20 mA current signals for controlling external devices. It offers high accuracy, reliability, and versatility, making it suitable for a wide range of industrial applications.
Technical Specifications
- Output Type: 4-20 mA
- Output Channels: 16
- Output Ripple: < 100 mV peak-to-peak at power line frequency, across 250 Ω load
- Output Temperature Drift: 0.005% of Full Scale/°C
- Output Readback Accuracy: ±4% of Full Scale
- Output Current Linearity: ±0.05% of Full Scale nominal
- Resolution: ±0.05% of Full Scale
- Calibrated Accuracy: ±0.35% of Full Scale (25°C) including linearity
- Directly Settable Output Current Range: 0 mA, 2.9 mA to 21.1 mA
- Maximum Resistive Load (24 V supply = 22 VDC through 28 VDC): 800 ohms
- Maximum Output Compliant Voltage (24 V supply = 22 VDC through 28 VDC): 16 V
- Maximum Open Circuit Voltage: 22 V
- Response Time (DAC input code to output): Settles to within 1% of final value within 80 ms
- Gap (0 mA) of Output to Field on Switchover: 10 ms maximum (applies to Redundancy only)
