Overview
The Trusted® Communications Interface (CI) is an advanced module designed to deliver diverse communication services for the Trusted Controller, thereby reducing the communication load on the Triple Modular Redundant (TMR) Processor. This module is user-configurable, allowing it to accommodate various communication media types. A Trusted System can support up to four Communications Interfaces (CIs) simultaneously.Specifications
-
Backplane (IMB) Supply: 20 Vdc to 32 Vdc
-
Field Supply: N/A
-
Power Dissipation: 10 W
-
Module Location: T8100, T8300 I/O Module Slot
-
Isolation:
-
50 V Basic Insulation:
-
Module to Backplane Supply
-
Module to Diagnostic Serial Port
-
-
250 V Basic Insulation:
-
Module to Rear Serial Ports
-
Module to Ethernet Ports
-
Serial Ports to Ethernet Ports
-
Between Serial Ports
-
Between Ethernet Ports
-
-
-
Fusing: Not User Serviceable
-
Ports:
-
2 Rear Serial Ports: RS-232/422/485
-
2 Rear Serial Ports: RS-422/485
-
2 Ethernet Ports: 10/100BaseT
-
1 Diagnostics Serial Port: RS-232
-
-
Baud Rates: 1200 baud to 115200 baud
-
Communications Protocols:
-
Modbus RTU
-
Open Modbus TCP
-
Trusted Peer to Peer
-
Trusted Enhanced Peer to Peer
-
ICS2000
-
CP2000
-
-
SOE Buffer: 4000 Events
-
Operating Temperature: 0 °C to +60 °C (+32 °F to +140 °F)
-
Storage Temperature: -25 °C to +70 °C (-13 °F to +158 °F)
-
Relative Humidity (Operating and Storage): 10% – 95%, non-condensing
-
Dimensions:
-
Height: 266 mm (10.5 in)
-
Width: 31 mm (1.2 in)
-
Depth: 303 mm (12.0 in)
-
-
Weight: 1.13 kg (2.49 lb)
