Overview
The Trusted® Communications Interface (CI) is an advanced, intelligent module designed to support various communication services for the Trusted Controller, significantly reducing communication load on the Triple Modular Redundant (TMR) Processor.
Specifications
-
Power Requirements
- Backplane (IMB) Supply: 20 Vdc to 32 Vdc
- Field Supply: Not applicable
- Power Dissipation: 10 W
-
Module Location
- Compatible Slots: T8100, T8300 I/O Module Slots
-
Isolation Ratings
-
50 V Basic Insulation:
- Module to Backplane Supply
- Module to Diagnostic Serial Port
-
250 V Basic Insulation:
- Module to Rear Serial Ports
- Module to Ethernet Ports
- Serial Ports to Ethernet Ports
- Between Serial Ports
- Between Ethernet Ports
-
50 V Basic Insulation:
-
Fusing
- Not user-serviceable
-
Ports
-
Serial Ports:
- 2 Rear Serial Ports, RS-232/422/485
- 2 Rear Serial Ports, RS-422/485
-
Ethernet Ports:
- 2 Ethernet Ports, 10/100BaseT
-
Diagnostic Serial Port:
- 1 Diagnostic Serial Port, RS-232
-
Serial Ports:
-
Baud Rates
- Ranges from 1200 baud to 115200 baud
-
Supported Communication Protocols
- Modbus RTU
- Open Modbus TCP
- Trusted Peer to Peer
- Trusted Enhanced Peer to Peer
- ICS2000
- CP2000
-
SOE Buffer Capacity
- 4000 Events
-
Environmental Conditions
- Operating Temperature: 0 °C to +60 °C (+32 °F to +140 °F)
- Storage Temperature: -25 °C to +70 °C (-13 °F to +158 °F)
- Relative Humidity (Operating and Storage): 10% – 95%, non-condensing
-
Physical Dimensions
- Height: 266 mm (10.5 in)
- Width: 31 mm (1.2 in)
- Depth: 303 mm (12.0 in)
- Weight: 1.13 kg (2.49 lb)
