Overview
The Trusted® TMR 24 Vdc Analog Input module connects to 40 sourcing field input devices, functioning as a current sink for all these devices. Each input channel undergoes thorough diagnostic testing to ensure reliability. Fault tolerance is built into the module using a Triple Modular Redundant (TMR) architecture, providing redundancy across all 40 input channels.Specifications
Backplane (IMB) Supply
- Voltage: 20 Vdc to 32 Vdc
- Power: 20 W
Field Supply: N/A
Maximum Power Dissipation: 20 W
Module Location: T8100, T8300 I/O Module Slot
Isolation
- Field Common: 50 V Reinforced (continuous), 250 V Basic (fault)
[Type tested at 2436 Vdc for 60 s] - Channel to Channel: None
- Fusing: None
Number of Inputs: 40
Input Specifications
- Impedance (FTA): 250 Ohm
- Impedance (module): 16.967 K Ohm
- Current: 0 mA – 22 mA
- Voltage: 0 Vdc – 5.5 Vdc
- Thresholds: Configurable
- Resolution (LSB): 3.906 μA
- Safety Accuracy: ±200 μA
- Calibration Accuracy: ±0.15 %
- Intrinsic Safety: None (External barrier required)
Sequence of Events
- Event Resolution (LSB): 1 ms
- Timestamp Accuracy: ±10 ms
Environmental Specifications
- Operating Temperature: 0 °C to +60 °C (+32 °F to +140 °F)
- Storage Temperature: -25 °C to +70 °C (-13 °F to +158 °F)
- Relative Humidity (Operating and Storage): 10% – 95%, non-condensing
Dimensions
- Height: 266 mm (10.5 in)
- Width: 31 mm (1.2 in)
- Depth: 303 mm (12.0 in)
- Weight: 1.149 kg (2.5 lb)
