Overview
The Model 4119A Enhanced Intelligent Communication Module (EICM) enables the Tricon system to interface with Modbus masters and slaves, TriStation 1131, and printers.
For Modbus connectivity, users can choose between an RS-232 point-to-point interface, supporting one master and one slave, or an RS-485 interface, which accommodates one master and up to 32 slaves. The RS-485 network can use one or two twisted-pair cables, with a maximum length of 4,000 feet (1,200 meters).
Specifications
- Model Number: 4119A, Isolated
- Serial Ports: 4 ports RS-232, RS-422, or RS-485
- Parallel Ports: 1, Centronics, isolated
- Port Isolation: 500 VDC
- Protocol: TriStation, Modbus
-
Modbus Functions Supported:
- 01 — Read Coil Status
- 02 — Read Input Status
- 03 — Read Holding Registers
- 04 — Read Input Registers
- 05 — Modify Coil Status
- 06 — Modify Register Content
- 07 — Read Exception Status
- 08 — Loopback Diagnostic Test
- 15 — Force Multiple Coils
- 16 — Preset Multiple Registers
- Communication Speed: 1200, 2400, 9600, or 19,200 Baud
-
Diagnostic Indicators:
- Pass
- Fault
- Active
- TX (Transmit) — 1 per port
- RX (Receive) — 1 per port
