Main Specifications
- Range of Product: Modicon Quantum automation platform
- Product or Component Type: Analogue input module
Complementary Specifications
- Analogue Input Number: 8
- Input Type: Differential
- Addressing Requirement: 9 input words
-
Analogue Input Type:
- Temperature probe: -100...450 °C for Pt 100, Pt 200, Pt 500, Pt 1000
- Temperature probe: -200...850 °C for Pt 100, Pt 200, Pt 500, Pt 1000
- Temperature probe: -60...180 °C for Ni 100, Ni 200, Ni 500, Ni 1000
- Temperature probe: 0.5 mA for Ni 100, Ni 200, Ni 500, Ni 1000
- Temperature probe: 2.5 mA for Pt 100, Pt 200, Ni 100, Ni 200
- Analogue Input Resolution: 13 bits
- Input Impedance: >= 10 MOhm
- Absolute Accuracy Error: 0.1 °C
-
Linearity Error:
- +/- 0.01% full scale
- +/- 0.5 °C
-
Accuracy Drift According to Temperature:
- +/- 0.5 °C at 25 °C
- +/- 0.9 °C at 0…60 °C
-
Isolation:
- Between channels and bus: 1780 V AC 47...63 Hz for 60 s; 2500 V DC for 60 s
- Between channels: 300 Vrms AC
-
Update Time:
- 1200 ms for 3 wires
- 640 ms for 2 wires/4 wires
- Fault Type: Broken wire
- Overtacking Scale: CE marking
Local Signaling
- 1 LED (green) for bus communication (Active)
- 1 LED (red) for external fault
- 8 LEDs (green) for channel turned on
- 8 LEDs (red) for channel fault
Power and Energy
- Bus Current Requirement: 200 mA
- Power Dissipation: 1 W
Physical Characteristics
- Module Format: Standard
- Net Weight: 0.3 kg
Environmental Specifications
- Standards: UL 508, CSA C22.2 No 142
- Product Certifications: FM Class 1 Division 2, cUL
-
Resistance to Electrostatic Discharge:
- 4 kV contact conforming to IEC 801-2
- 8 kV on air conforming to IEC 801-2
-
Resistance to Electromagnetic Fields:
- 10 V/m 80…1000 MHz conforming to IEC 801-3
- Ambient Air Temperature for Operation: 0…60 °C
- Ambient Air Temperature for Storage: -40…85 °C
- Relative Humidity: 95% without condensation
- Operating Altitude: <= 5000 m
Packing Information
- Package Type: PCE
- Number of Units in Package: 1
-
Package Dimensions:
- Height: 4.7 cm
- Width: 16.5 cm
- Length: 31.4 cm
- Package Weight: 440.0 g
