Specifications
Main Specifications
- Product Range: Modicon Quantum automation platform
- Product Type: Processor
- Software Name: ProWORX 32
- Processor Name: 80486
- Mathematical Coprocessor: Yes
- Clock Frequency: 66 MHz
Memory and Performance
- Internal RAM: 896 kB
- Exact Time for 1 K-Instruction: 0.1...0.5 ms (LL984)
- Watchdog Timer: 250 ms
- Clock Drift: +/-8 s/day
- Operating Temperature Range: 32…140 °F (0…60 °C)
I/O and Networking
- Distributed I/O Words: 30 I/32 O
- Max Local I/O Words: 64 I/64 O
- Max Remote I/O Words: 64 I/64 O
- I/O Words per Network: 500 I/500 O
- Distributed Drops per Network: 63
- Remote Drops per Network: 31
- Number of Networks: 2 remote, 3 distributed
Battery and Power
- Battery Type: Lithium
- Battery Consumption: 7 µA standby, 210 µA active
- Battery Capacity: 1.2 Ah
- Battery Life: 10 years
Ports and Communication
- Modbus Plus Port: 1
- Modbus RS232 Ports: 2
- Communication Module Processor Capacity: 6 NOM, NOE, CR, NMS
- Switch Function: Key switch
- Marking: CE
Electrical and Mechanical Specifications
- Bus Current Requirement: 1250 mA
- Module Format: Standard
- Net Weight: 1.87 lb (0.85 kg)
Environmental Specifications
-
Product Certifications:
- FM Class 1 Division 2
- cUL
-
Standards Compliance:
- UL 508
- CSA C22.2 No 142
-
Electrostatic Discharge Resistance:
- 4 kV contact (IEC 801-2)
- 8 kV on air (IEC 801-2)
-
Electromagnetic Field Resistance:
- 9.1 V/m (10 V/m) 80…2000 MHz (IEC 801-3)
- Operating Temperature Range: 32…140 °F (0…60 °C)
- Storage Temperature Range: -40…185 °F (-40…85 °C)
- Relative Humidity: 95% without condensation
- Operating Altitude: ≤ 16404.2 ft (5000 m)
Ordering and Shipping Details
- Category: 18150-QUANTUM CONTROLLERS,HSBY,COMM.
- Discount Schedule: PC21
- GTIN: 3595862014304
- Returnability: No
- Country of Origin: France
Packaging Information
- Package Type: PCE
- Units per Package: 1
-
Package Dimensions:
- Height: 1.73 in (4.4 cm)
- Width: 6.50 in (16.5 cm)
- Length: 12.20 in (31 cm)
- Package Weight: 21.5 oz (609 g)
