Main Information
- Range of product: Modicon Quantum
- Product or component type: Ethernet RIO drop adaptor
- Number of ports: 3
-
Integrated connection type:
- Ethernet IP/Modbus TCP for service port
- Ethernet IP/Modbus TCP for device network
- Communication port protocol: Ethernet IP/Modbus TCP
-
Communication service:
- Input data is collected and published to the remote I/O head adaptor.
- Output modules are updated with the data received from the remote I/O head adaptor.
Complementary Information
- Topology: Daisy chain loop
-
Local signaling:
- 1 LED (green/red) for module status (Mod Status)
- 1 LED (green/red) for network communication status (Net Status)
- 1 LED (green) for RUN
- 1 LED (red) for I/O
- Product compatibility: 140CRP31200
- Environmental characteristic: Standard environment
- Hazardous location: Class I division 2 conforming to EN/IEC 61131-1
-
Dimensions:
- Width: 167 mm
- Height: 50 mm
- Net weight: 0.554 kg
Environment
-
Product certifications:
- CE
- UL 508
- C-Tick
-
Standards:
- IEC 55011
- CSA C22.2 No 142
- IEC 61000-4-16
-
IP degree of protection:
- IP20 conforming to IEC 61131-2
- IP20 conforming to IEC 60527
- Overvoltage category: Class I conforming to IEC 61131-2
-
Ambient air temperature for operation:
- 0…60 °C conforming to IEC 60068-2-2
-
Ambient air temperature for storage:
- -40…85 °C conforming to IEC 60068-2-2
-
Vibration resistance:
- 3.5 mm constant amplitude (f= 0.5…8.4 Hz) conforming to IEC 61131-2
- 1 gn constant acceleration (f= 8.4…150 Hz) conforming to IEC 61131-2
- Operating altitude: 2000 m
- Maximum altitude for transport: 3000 m
- Relative humidity: 93 % conforming to IEC 60068
Packing Units
-
Unit Type of Package 1: PCE
- Number of Units in Package 1: 1
-
Package 1 Dimensions:
- Height: 4.9 cm
- Width: 16.4 cm
- Length: 31.3 cm
- Package 1 Weight: 593 g
-
Unit Type of Package 2: S03
- Number of Units in Package 2: 7
-
Package 2 Dimensions:
- Height: 30.0 cm
- Width: 30.0 cm
- Length: 40.0 cm
- Package 2 Weight: 4.65 kg
