Main Product Information
- Product Range: Modicon Quantum automation platform
- Product Type: RIO drop adaptor module
- Product Compatibility: Quantum
Technical Specifications
- Maximum Number of I/O Expansion Modules: 27
- Cable Type: 75 Ohm coaxial
- Transmission Rate: 1544 Mbit/s
- Dynamic Range: 35 dB
- Isolation Voltage: 500 V DC (coaxial center and ground)
-
Electrical Connection:
- 1 female connector F, elbowed with a single cable
-
Diagnostics:
- Startup Executive checksum
- RAM address/data during power up and runtime
- Power Dissipation: 3 W (1 channel)
- Bus Current Requirement: 600 mA (1 channel)
- Module Format: Standard
Environmental Conditions
-
Resistance to Electrostatic Discharge:
- 4 kV contact (IEC 801-2)
- 8 kV air (IEC 801-2)
-
Resistance to Electromagnetic Fields:
- 9.14 V/m (10 V/m) at 80…1000 MHz (IEC 801-3)
- Ambient Air Temperature for Operation: 32…140 °F (0…60 °C)
- Ambient Air Temperature for Storage: -40…185 °F (-40…85 °C)
- Relative Humidity: 95% without condensation
- Operating Altitude: ≤ 16,404.2 ft (5000 m)
Ordering and Shipping Details
- Category: 18155 - QUANTUM I/O & POWER SUPPLIES
- Discount Schedule: PC21
- GTIN: 00785901793083
- Number of Units in Package: 1
- Package Weight: 1.12 lb (0.51 kg)
- Returnability: No
- Country of Origin: France
Packing Units
-
Unit Type of Package 1: PCE
- Package 1 Height: 1.97 in (5 cm)
- Package 1 Width: 6.50 in (16.5 cm)
- Package 1 Length: 12.20 in (31 cm)
-
Unit Type of Package 2: S03
- Number of Units in Package 2: 7
- Package 2 Weight: 8.71 lb (3.951 kg)
- Package 2 Height: 11.81 in (30 cm)
- Package 2 Width: 11.81 in (30 cm)
- Package 2 Length: 15.75 in (40 cm)
