Main Information
- Range of Product: Modicon Quantum automation platform
- Product/Component Type: RIO head-end adaptor module
Complementary Information
-
Product Compatibility:
- Quantum 200/500/800 series
- Symax (any mix)
- Number of Drops/Network: ≤ 31
- I/O Words per Drop: 64 I / 64 O
- Type of Cable: Coaxial 75 Ohm
- Transmission Rate: 1544 Mbit/s
- Dynamic Range: 35 dB
- Isolation Voltage: 500 V DC between coaxial center and ground
- Electrical Connection: 1 female connector F elbowed with a single cable
-
Diagnostics Startup:
- Memory check
- Power-up
- LAN controller check
- Power Dissipation: 3 W (1 channel)
- Marking: CE
- Bus Current Requirement: 600 mA (1 channel)
- Module Format: Standard
Environment
-
Product Certifications:
- FM Class 1 Division 2
-
Standards:
- UL 508
- CUL
- CSA C22.2 No 142
-
Resistance to Electrostatic Discharge:
- 4 kV contact (conforms to IEC 801-2)
- 8 kV air (conforms to IEC 801-2)
- Resistance to Electromagnetic Fields: 9.14 V/yd (10 V/m) at 80-1000 MHz (conforms to IEC 801-3)
- Ambient Air Temperature for Operation: 32...140 °F (0...60 °C)
- Ambient Air Temperature for Storage: -40...185 °F (-40...85 °C)
- Relative Humidity: 95% without condensation
- Operating Altitude: ≤ 16404.2 ft (5000 m)
Ordering and Shipping Details
- Category: 18155 - Quantum I/O & Power Supplies
- GTIN: 00785901793113
- Number of Units in Package: 1
- Package Weight: 1.11 lbs
- Returnability: Yes
- Country of Origin: France (FR)
