Main Specifications
- Range of Product: Modicon Quantum Automation Platform
- Product or Component Type: Ethernet Network TCP/IP Module
- Concept: Transparent Ready
- Web Server: Class B30
-
Web Services:
- Diagnostics via predefined web pages
- Rack viewer
- Data editor (via PC terminal)
-
Communication Service:
- SNMP network management
- Bandwidth management
- Global Data
- I/O scanning
- Modbus TCP messaging
- FDR server
- Communication Port Protocol: Ethernet Modbus TCP/IP
-
Physical Interface:
- MT/RJ - 100BASE-FX fiber optic
- RJ45 - 10BASE-T/100BASE-TX twisted pair
- Transmission Rate: 10/100 Mbit/s
Complementary Specifications
- Redundancy: Yes, hot standby redundant architecture
- Power Supply: Via the power supply of the rack
- Marking: CE
Local Signalling (LED Indicators)
- 10 Mbps or 100 Mbps data rate (10 MB/100 MB) - 1 LED
- Collision detection (Coll) - 1 LED
- Download mode (Kernel) - 1 LED
- Ethernet module fault (Fault) - 1 LED
- Ethernet network status (RUN) - 1 LED
- Full-duplex mode (Fduplex) - 1 LED
- Module ready (Ready) - 1 LED
- Network active (Link) - 1 LED
- Rack operational (Active) - 1 LED
- Transmission/reception activity (TxAct/RxAct) - 1 LED
Power Consumption
- Current Consumption: 750 mA at 5 V DC
- Module Format: Standard
- Net Weight: 0.761 lb (0.345 kg)
Environment
- IP Degree of Protection: IP20
-
Product Certifications:
- cUL
- UL 508
-
Standards:
- CSA C22.2 No 142
- FM Class 1 Division 2
Resistance to Environmental Factors
-
Electrostatic Discharge:
- 4 kV contact (IEC 801-2)
- 8 kV on air (IEC 801-2)
-
Electromagnetic Fields:
- 9.1 V/yd (10 V/m) at 80...1000 MHz (IEC 801-3)
Operating Conditions
-
Ambient Air Temperature:
- Operation: 32 to 140°F (0 to 60°C)
- Storage: -40 to 185°F (-40 to 85°C)
- Relative Humidity: 95% without condensation
- Operating Altitude: ≤ 4500 m
Packaging Information
- Unit Type of Package: PCE
- Number of Units in Package: 1
-
Package Dimensions:
- Height: 2.0 in (5.0 cm)
- Width: 6.7 in (17.0 cm)
- Length: 12.4 in (31.5 cm)
- Weight: 19.8 oz (560 g)
