Main Specifications
- Product Type: DIO head-end adaptor
-
Number of Ports:
- 1 Modbus Plus fiber optic (single copper)
- 1 Modbus RS232 (twisted pair)
- Transmission Rate: 1 Mbit/s
-
Electrical Connection:
- 1 RJ45 connector
- 2 TX/RX connectors
- I/O Words: 30 I / 32 O
- Checks: Checksum
Processor
- RAM: [Specifications not provided]
- RAM Address: [Specifications not provided]
- Power Dissipation: 4 W
- Pulse Width Distortion/Jitter: ≥ 5 ns
- Wavelength: 820 nm
Power Loss Budget
- 11 dB (62.5/125 µm)
- 16.5 dB (100/140 µm)
- 6.5 dB (50/125 µm)
Optical Transmission
-
Optical Levels:
- -16...-9 dBm (100/140 µm)
- -19.8...-12.8 dBm (50/125 µm)
- -3.5...110.5 dBm (62.5/125 µm)
- Rise/Fall Time: 20 ns
- Dynamic Range: 20 dB
- Detected Silence: -36 dBm
- Sensitivity Scale: > 30 dBm
- Bus Current Requirement: 750 mA
Environmental Specifications
-
Resistance to Electrostatic Discharge:
- 4 kV contact (IEC 801-2)
- 8 kV on air (IEC 801-2)
-
Resistance to Electromagnetic Fields:
- 10 V/m (80...2000 MHz, IEC 801-3)
- Ambient Air Temperature for Operation: 0...60 °C
- Ambient Air Temperature for Storage: -40...85 °C
- Relative Humidity: 95 % without condensation
- Operating Altitude: ≤ 5000 m
Standards and Certifications
- Standards: UL 508
-
Certifications:
- CSA Class 1 Division 2
- C-Tick
- DNV
- GL
- GOST
- RINA
- RMRS
