Modicon Momentum Automation Platform - M1/M1E Processor Adaptor
Main Characteristics
- Product Range: Modicon Momentum automation platform
- Product Type: M1/M1E processor adaptor
-
Software Compatibility:
- Concept V2.6
- Modsoft ≥ V2.5
- ProWORX NxT V2.0
- ProWORX 32
- Communication Protocol: Modbus
- Processor Name: x86 based (Intel, AMD)
- Clock Frequency: 32 MHz
Memory and Processor
- Discrete I/O Processor Capacity: 8192 I/O (inputs/outputs)
- Register I/O Processor Capacity: 26048 I/O
- I/O Limit Processor Capacity: 8192 bits maximum
-
Memory Type:
- 512 KB Flash
- 512 KB RAM
-
Memory Description:
- Program Memory:
- 18 KB LL984
- 240 KB IEC
- Data: 24 KB
- Program Memory:
Electrical Characteristics
- Supply Voltage: 5.0 V DC ±5%
- Supply Source: By Momentum I/O base
- Exact Time for 1 Kinstruction: 1 ms
- Word Length: 16-bit
Physical Characteristics
- Material: Lexan
-
Weight:
- Net Weight: 0.093 lb (0.042 kg)
Environmental Specifications
- Operating Temperature: 32…140 °F (0…60 °C)
- Storage Temperature: -40…185 °F (-40…85 °C)
- Relative Humidity: 5…96%, without condensation
- Operating Altitude: 6561.68 ft (2000 m)
- Shock Resistance: ≤ 15 gn peak, 11 ms half-sine wave acceleration
- Vibration Resistance: 0.75 mm d.a, 1 gn
Certifications
- FM Class 1 Division 2
- UL
- NEMA Type 250
- cUL
Packaging Details
- Category: 18206-MOMENTUM PROCESSORS, I/O BASES, CONN.
- Discount Schedule: PC31
- GTIN: 3595860010728
- Returnability: No
- Country of Origin: France
Packaging Units
-
Package 1:
- Type: PCE
- Number of Units: 1
- Dimensions:
- Height: 2.17 in (5.5 cm)
- Width: 7.09 in (18 cm)
- Length: 10.24 in (26 cm)
- Weight: 7.6 oz (215 g)
-
Package 2:
- Type: S02
- Number of Units: 4
- Dimensions:
- Height: 5.91 in (15 cm)
- Width: 11.81 in (30 cm)
- Length: 15.75 in (40 cm)
- Weight: 2.518 lb (1.142 kg)
-
Package 3:
- Type: S03
- Number of Units: 8
- Dimensions:
- Height: 11.81 in (30 cm)
- Width: 11.81 in (30 cm)
- Length: 15.75 in (40 cm)
- Weight: 4.927 lb (2.235 kg)
