Specifications
Main Specifications:
- Range of Product: Modicon Momentum automation platform
- Product or Component Type: M1/M1E processor adaptor
- Concept: Transparent Ready
- Level or Class: Class B10
-
Software Designation:
- Concept V2.6
- Modsoft >= V2.5
- ProWORX NxT V2.0
- ProWORX 32
- Communication Port Protocol: Ethernet
- Processor Name: X 86 based (INTEL, AMD)
- Clock Frequency: 50 MHz
Complementary Features:
-
Web Services:
- Web page loader software tool
- Rack viewer
- Data editor
- Web page loader
-
Ethernet Services:
- I/O scanning
- Modbus TCP messaging
Processor and Memory Specifications:
- Discrete I/O Processor Capacity: 8192 I/8192 O
-
Memory Type:
- 512 KB flash
- 544 kB RAM
-
Memory Description:
- Program memory: 18 kB LL984
- Data: 24 kB
- Word Length: 16 bit
- Supply Voltage: 5.0 V DC ±5 %
- Exact Time for 1 K-instruction: 1 ms
- Register I/O Processor Capacity: 26048 I/26048 O
- I/O Limit Processor Capacity: 8192 bits max
-
I/O Words/Drop:
- 128 I/O Concept
- 80 I/O ProWORX
Physical and Environmental Specifications:
- Material: Lexan
- Marking: CE
- Net Weight: 0.093 lb (0.042 kg)
-
Ambient Air Temperature:
- Operating: 32…140 °F (0…60 °C)
- Storage: -40…185 °F (-40…85 °C)
- Relative Humidity: 5…96 % (without condensation)
- Operating Altitude: 6561.68 ft (2000 m)
- Shock Resistance: <= 15 gn peak, 11 ms half sine wave acceleration
-
Vibration Resistance:
- 0.75 mm d.a
- 1 gn
Certifications:
-
Product Certifications:
- NEMA Type 250
- FM Class 1 Division 2
- cUL
- UL
Ordering and Shipping Details:
- Category: 18206-MOMENTUM PROCESSORS, I/O BASES, CONN.
- Discount Schedule: PC31
- GTIN: 3595860019318
- Returnability: No
- Country of Origin: France
Packing Details:
-
Unit Type of Package 1:
-
Package 1 Dimensions:
- Height: 2.17 in (5.5 cm)
- Width: 7.09 in (18 cm)
- Length: 10.24 in (26 cm)
- Weight: 7.1 oz (202 g)
- Number of Units in Package 1: 1
-
Package 1 Dimensions:
-
Unit Type of Package 2:
-
Package 2 Dimensions:
- Height: 5.91 in (15 cm)
- Width: 11.81 in (30 cm)
- Length: 15.75 in (40 cm)
- Weight: 2.482 lb (1.126 kg)
- Number of Units in Package 2: 4
-
Package 2 Dimensions:
-
Unit Type of Package 3:
-
Package 3 Dimensions:
- Height: 11.81 in (30 cm)
- Width: 11.81 in (30 cm)
- Length: 15.75 in (40 cm)
- Weight: 4.698 lb (2.131 kg)
- Number of Units in Package 3: 8
-
Package 3 Dimensions:
