Overview
The Siemens Digital Output Module (6ES7422-1BL00-0AA0) ensures reliable digital output performance for industrial automation tasks.
Voltage and Power Specifications
-
Supply Voltage:
-
Rated Value: 24 V DC
-
Permissible Range: 20.4 V to 28.8 V DC
-
Load Voltage L+:
-
Input Current:
-
From Load Voltage L+ (without load): Max. 30 mA
-
From Backplane Bus 5 V DC: Max. 200 mA
Power Loss
-
Typical Power Loss: 4 W
Digital Outputs and Capacity
-
Number of Digital Outputs: 32
-
Inductive Shutdown Voltage Limit: -27 V
-
Switching Capacity on Lamp Load: Max. 5 W
Potential Separation and Isolation
-
Potential Separation:
-
Between Channels: In groups of 32
-
Between Channels and Backplane Bus: Yes
-
Isolation: Tested with 500 V DC
Physical Dimensions
-
Dimensions:
-
Width: 25 mm
-
Height: 290 mm
-
Depth: 210 mm
-
Weight: Approx. 600 g
