Overview
The YOKOGAWA NFAI835-S50 Analog Input/Output Module is a versatile device designed for industrial automation applications. It provides both input and output channels for analog signals, making it suitable for various process control tasks.
Technical Specifications
General
- Model: NFAI835-S50
- Number of I/O Channels: 4-channel input/4-channel output, isolated channels
-
I/O Signal:
- Input: 4 to 20 mA
- Output: 4 to 20 mA
- Allowable Input Current: 25 mA
- Overcurrent Protection: Provided
-
Withstanding Voltage:
- Between input/output and system: 500 V AC for 1 minute
- Between channels: 500 V AC for 1 minute
-
Input Resistance:
- Power ON: 250 Ω
- Power OFF: 500 kΩ or more
- Allowable Load Resistance: 0 to 750 Ω
- Circuit-Open Detection: 0.65 mA or less
-
Accuracy:
- Inputs: ±0.1% of full scale
- Outputs: ±0.3% of full scale
- Data Refresh Cycle: 10 ms
- Input Step Response Time: 100 ms
- Output Step Response Time: 100 ms
- Output Fallback: Set for each channel
- Transmitter Power Supply: 20.2 to 29.3 V
- Temperature Drift: Max. ±0.01%/°C
-
Maximum Current Consumption:
- 360 mA (5 V DC)
- 450 mA (24 V DC)
- Weight: 0.3 kg
- External Connection: Pressure clamp terminal, MIL connector cable
