Overview
The Modicon Momentum Fipio Communication Adaptor is part of the Modicon Momentum range. It is a flexible, modular family of fundamental components for distributed control architecture. This product is designed to support Fipio communication with 1 Mbps transmission rate, offering multiple transmission mediums including optical fibre (50/125, 62.5/125) and twisted shielded pairs cable.
- Applications: Primarily used in infrastructures, energy, material handling, and simple machine control.
- Certification: CE, UL, and CSA certified.
-
Key Features:
- Allows for direct connection to the Fipio Network for Momentum I/O modules.
- Can be plugged into a Momentum I/O base to form a functional I/O unit.
Specifications
Main Features
- Range of Product: Modicon Momentum automation platform
- Product Type: Fipio communication adaptor
- Bus Manager PLC: Premium
- Structure Type: Open industrial support, conforming to Fip standard
- Communication Port Protocol: Fipio
- Method of Access: Producer/consumer principle
- Transmission Rate: 1 Mbit/s
-
Transmission Support Medium:
- Optical fibre (50/125)
- Twisted shielded pairs cable
- Optical fibre (62.5/125)
Complementary Features
- Topology: Extension or tap-off cable
-
Number of Devices per Segment:
- Without repeater: 0–31 devices
- With repeater: 0–97 devices
- Maximum Cable Distance between Devices: 5000 m (16404.2 ft)
-
Fail State:
- Maintain value
- Forcing to state zero
- Full Scale Value: Fallback to zero
- Supply: From I/O base
- Marking: CE
Local Signalling
- RUN LED (Green): Powered up or in service
- ERR LED (Red): Fault state
- COM LED (Yellow): Receiving or sending data
Physical Characteristics
- Net Weight: 0.11 kg (0.24 lb)
Environment
- Product Certifications: CE, UL, CSA
- Protective Treatment: TC
-
Resistance to Electrostatic Discharge:
- 4 kV contact (IEC 801-2)
- 8 kV on air (IEC 801-2)
- Resistance to Electromagnetic Fields: 9.1 V/m (10 V/m) 80–1000 MHz (IEC 801-3)
- Ambient Air Temperature for Operation: 0…60 °C (32…140 °F)
- Ambient Air Temperature for Storage: -40…85 °C (-40…185 °F)
- Relative Humidity: 95 % without condensation
- Operating Altitude: ≤ 5000 m (16404.2 ft)
Ordering and Shipping Details
- Category: US1PC3118206
- Discount Schedule: PC31
- GTIN: 3389110896527
- Returnability: No
- Country of Origin: US
Package Information
- Unit Type of Package 1: PCE
- Number of Units in Package 1: 1
-
Package 1 Dimensions:
- Height: 5.5 cm (2.17 in)
- Width: 18.0 cm (7.09 in)
- Length: 26.0 cm (10.24 in)
- Weight: 185 g (6.5 oz)
